Oil Filtration Work Station

Bunded Work Station Suitable for servicing or as a permanent connection to medium tanks to ideally around 1000ltr.

• Height: 548 mm
• Width: 560 mm
• Depth: 860 mm
• Weight: 98kg
• Water Retention: 1560ml
• Flow rate: 500lph

Comes as standard ‘240v progressive cavity pump/motor‘
(110v or 415v OPTIONAL EXTRA) Call us direct to arrange different pumps.

🔹 Product Overview

The KLEENOIL MS2 Bunded Workstation is a robust, high-performance twin-filter off-line oil filtration system designed for both fixed installation and flexible servicing applications. Engineered for reliability in demanding industrial environments, this compact workstation delivers continuous, high-efficiency filtration for hydraulic, gear, and transmission systems, as well as diesel fuel and stored oils.

With an integrated bunded base for safe fluid containment, the MS2 ensures clean, controlled operation while supporting routine maintenance, oil reclamation, and system protection.

🔹 Performance & Capability

Operating as an off-line filtration system, the MS2 continuously circulates oil through its dual filtration vessels, removing contamination without interrupting system operation.

Utilising KLEENOIL’s proven cellulose filter technology, the system:

• Removes particulate contamination down to 3 microns
• Removes free and dissolved water contamination
• Achieves high levels of oil cleanliness (typically ISO 4406 14/9)

The twin-filter configuration delivers an approximate flow rate of 500 litres per hour, enabling rapid cleaning of tanks up to approximately 2000 litres, making it ideal for both maintenance and fluid recovery applications.

🔹 Key Applications

• Hydraulic, gear & transmission fluid reservoir cleaning
• Oil and diesel fuel transfer
• Cleaning stored or unused oils prior to use
• Routine maintenance and system flushing
• Rotational servicing of industrial equipment

🔹 Key Benefits

• High-capacity twin filtration for faster cleaning
• Removes ultra-fine contamination and water
• Extends oil life and reduces replacement frequency
• Reduces downtime and maintenance costs
• Suitable for both permanent installation and mobile servicing
• Bunded design for safe spill containment

🔹 System Features

• Twin filter vessel configuration for increased throughput
• Heavy-duty industrial construction
• Bunded base for environmental protection and spill control
• Integrated pump system delivering consistent flow
• Pressure gauge, bypass valve, and safety cut-off protection
• Sampling ports for oil condition monitoring
• Supplied with suction and return hoses
• Mounted on a durable, mobile or fixed workstation frame

Designed for ease of use, the MS2 offers simple plug-and-play operation while maintaining high levels of operational safety and filtration efficiency.

🔹 Technical Highlights

• Filtration: 3 micron (cellulose media)
• Flow Rate: Approx. 500 LPH
• Water Removal: High-efficiency absorption
• Tank Capacity: Suitable for systems up to ~2000L
• Media Compatibility: Mineral, synthetic oils, diesel, turbine & hydraulic fluids
• System Type: Twin filter off-line workstation

🔹 Quality & Build

Manufactured in the UK using high-quality components, the MS2 Bunded Workstation is built for long-term reliability in industrial applications. The system includes integrated safety features, robust construction, and is supplied with a full instruction manual and 12-month warranty for complete peace of mind.

KLEENOIL Manufacture - call us to discuss your application ; We not only adapt to suit your needs but offer a full support service to ensure you achieve the filtration cleanliness standard you need - and we can offer free trials to demonstrate the ability of the KLEENOIL System, - Tel U.K 44 (0) 1977 682810

🔹 How the Mobile Filtration System Works

KLEENOIL mobile filtration systems are designed for simple, on-site operation, allowing you to quickly clean oil or fuel in tanks, IBCs, or machinery sumps.

At site:

• Position the unit as close as possible to the tank, IBC, or system
• Connect to a suitable power source (typically 240V)
• Place the feed hose into the tank (or connect to an available port – standard ¾")
• Position the return hose back into the tank, ideally as far from the feed point as practical to promote circulation

Once both hoses are submerged:

• Turn the isolator switch to ON
• Press the green start button
• Allow the system to prime—the filtration process begins immediately

The unit will continuously circulate and clean the oil. Run the system until the desired level of cleanliness is achieved. For best results, it is recommended to take a visual before-and-after sample to monitor improvement.

🔹 Maintenance & Servicing

• Cartridge changes: Follow the standard replacement procedure (see “Filter Replacement” section in replacement cartridges )
• Micromag: Periodically wipe clean during cartridge changes
• General operation: The system is designed to be low maintenance and trouble-free
